Automatic circular winding machine is a BOYAN motor-driven platform described for braiding-related and coil-winding applications where a neat circular formation is required. The verified reference lists model PWD-M-30, a machine weight of 60 kg, a motor as the core component and overall dimensions of 710 × 670 × 390 mm. The source title states that the machine is suitable for braiding and coil winding and aims for neat, attractive winding.
Those terms do not define the workpiece, material or winding pattern. A circular rope assembly, toroidal coil, decorative cord ring and braided product require different tooling and controls. Send the product drawing, material, supply package, accepted sample and required cycle to yangle990706@gmail.com for a BOYAN configuration review.
Automatic Circular Winding Machine: Quick Selection Guide
An automatic circular winding machine may fit a project when the product has a circular path and the required formation can be described by dimensions, pattern and appearance criteria. The source supports the broad braiding and coil-winding direction. It does not publish speed, torque, tension, product diameter, material range, winding accuracy, PLC, servo or feeder details.
- Model: PWD-M-30.
- Machine weight: 60 kg.
- Machine size: 710 × 670 × 390 mm.
- Core component: motor.
- Source applications: braiding-related and coil winding.
- Source quality objective: neat, attractive circular formation.
- Open fields: workpiece, material, range, speed, tension, controls and output.
BOYAN translates the visual quality objective into measurable criteria such as pitch, gaps, overlap, edge shape, layer distribution and surface damage.
Verified Specification and Documentation Boundary
| Item | Available reference | BOYAN confirmation |
|---|---|---|
| Model | PWD-M-30 | Final model and nameplate |
| Machine weight | 60 kg | Net weight of supplied build |
| Machine size | 710 × 670 × 390 mm | Approved outline and service clearance |
| Core component | Motor | Motor rating, drive and controls |
| Process direction | Braiding and coil winding | Exact workpiece and winding sequence |
| Quality wording | Neat and attractive winding | Measurable visual and dimensional criteria |
| Package size | 75 × 70 × 51 cm | Final export packing data |
| Package gross weight | 60 kg | Final shipping weight |
| EU label | “EU standards compliant” displayed | Documents, model scope and destination rules |
| Performance | Not published | Speed, tension, accuracy, product range and output |
The listed gross weight equals the machine weight, which may omit packing material. BOYAN will confirm the final gross weight before freight planning.
Define the Circular Product
Provide outside diameter, inside diameter, cross-section, winding width, material path and finished mass. State whether the product is a rigid ring, flexible loop, toroidal core, rope coil, decorative circle or another geometry. If the product opens during loading, show the fixture and closure.
For a toroidal or ring core, describe how material passes through the center. For a rope coil, explain whether the machine forms a storage coil or wraps one material around another. For a braiding-related product, state whether braiding occurs on this machine or upstream.
The automatic circular winding machine source does not define these mechanisms. BOYAN uses the real product and cycle to select tooling.
Material and Supply Requirements
The old page claimed braided rope, textile cord, decorative wire and precision coil compatibility. The source title supports braiding and coil winding generally, but provides no material list or range. Each material must be checked by sample.
- Material name, grade, construction and diameter or width.
- Stiffness, elasticity, twist and minimum bend radius.
- Surface coating, abrasion and allowable marks.
- Supply package dimensions, full mass and unwind method.
- Target tension or finished tightness when measurable.
- Representative accepted and difficult samples.
A stiff wire, soft cord and braided rope behave differently during circular winding. The accepted material range should appear in the final proposal.
Neat and Uniform Formation
The source title uses neat and attractive winding wording. To make it testable, define pitch, overlap, gaps, layer count, edge buildup, crossover, deformation and surface damage. Provide accepted and rejected samples where appearance is important.
No numerical winding accuracy or tension range is published. The old page’s uniform-layer and high-precision claims are therefore replaced by an agreed sample and inspection method. An automatic circular winding machine should be accepted from finished output, not an unsupported adjective.
If the product must unwind later, include an unwind test. A visually neat package can still snag, collapse or introduce variable tension downstream.
Tooling, Opening and Material Passage
Circular products may require an opening mechanism or special shuttle to pass material through the center. The source does not describe whether the ring opens, rotates, or uses another arrangement. Provide core geometry and show how material should be loaded.
Tooling must retain the product while avoiding marks or distortion. For several sizes, list the range and changeover frequency. The 710 × 670 × 390 mm machine dimensions do not establish maximum product diameter.
BOYAN will define included fixtures and change parts for the automatic circular winding machine quotation.
Five Applications to Evaluate
1. Braided Rope Circular Formation
The source title supports a braiding-related use. Provide the braided rope, ring geometry and whether the machine winds or braids.
2. Toroidal Core Winding
A ring or toroidal core can be evaluated when opening, passage, wire or cord, turns and insulation are defined.
3. Decorative Circular Cord Products
The automatic circular winding machine may be reviewed for decorative circular products where appearance and pattern criteria are supplied.
4. Rope or Cord Coil Preparation
A circular storage or process coil can be evaluated from coil diameter, width, material, tie-off and downstream handling.
5. Custom Ring-Shaped Components
Other products can be reviewed from drawings, materials and samples. Safety-critical or electrical claims require separate standards and tests.
Automation Boundary and Output
“Automatic” appears in the source title but no full cycle is published. Identify who loads the core or product, threads material, anchors the start, starts, cuts, secures and unloads. If the product or ring opens, define that step.
Automatic feeding, cutting, tying, bonding or discharge are not confirmed. Sensors for missing product, material break, jam and incomplete winding should be specified when required.
No speed or output figure is published. Accepted pieces per hour should include manual work, changeover, inspection and rework. Record stable output during the trial.
Controls and Electrical Requirements
The verified record identifies a motor only. PLC appears on the old page as an optional upgrade claim without source parameters and is removed. Servo, touchscreen, recipe storage and constant-tension control are also unconfirmed.
Provide destination voltage, phase, frequency and plant standard. If recipes, counters, password levels, fault history, barcode selection or line integration are needed, list them. BOYAN will state actual controls in the final automatic circular winding machine proposal.
EU Label and Compliance
The source page displays an EU-standards label. Before relying on it, request applicable documents, verify the model and review configuration limitations. Destination regulations and machine modifications may change the scope.
BOYAN will identify available documentation for the ordered build. A marketplace label is not presented as independent proof.
Safety and Risk Assessment
Rotating rings, cores, material and fixtures can create entanglement, pinch and impact hazards. Material passing through a center opening may create additional moving zones. Guards, emergency stops, safe setup, isolation and training are required.
The buyer should assess loading, opening or closing tooling, threading, winding, jam clearing, cutting, unloading and maintenance. General principles appear in the OSHA machine-guarding guidance; local rules govern the final installation.
Never guide material by hand near a rotating product. Stop and isolate before correcting layers or changing tooling.
Recommended Sample Trial
- Approve the product: identify ring, core or coil drawing and sample.
- Verify material: record construction, size and supply package.
- Map the cycle: mark loading, threading, winding, cutting and unloading.
- Set acceptance: define turns, pitch, gaps, overlap, surface and output.
- Install tooling: check retention, opening, clearance and guarding.
- Run slowly: observe material passage, tracking and deformation.
- Increase rate: maintain the accepted formation.
- Inspect or unwind: test the product by the agreed method.
- Repeat: run multiple cycles and a normal size change.
Factory Acceptance Checklist
- PWD-M-30 model, 60 kg weight and 710 × 670 × 390 mm size are verified.
- Motor, drive, controls and destination electrical ratings are recorded.
- Included tooling fits the buyer’s minimum and maximum products.
- Manual and automatic cycle steps match the agreed scope.
- Guards, emergency stops and restart behavior are demonstrated.
- The buyer’s core and material complete repeated cycles.
- Turns, pitch, layer, appearance and surface criteria pass.
- Cycle time, operator work, faults and rejects are recorded.
- Changeover and normal fault recovery are demonstrated.
- Manuals, drawings, parts, documents and open actions are listed.
- 75 × 70 × 51 cm packing and final gross weight are verified.
Information Needed for a Proposal
- Ring, toroid, rope coil or finished product drawing.
- Material grade, construction, size and sample.
- Supply package drawing and unwind method.
- Turns, pitch, layers, direction, ends and visual criteria.
- Required opening, passage, loading and unloading sequence.
- Target output, shifts, lot size and changeovers.
- Manual and automatic cycle steps.
- Voltage, phase, frequency, destination and plant standard.
- Guarding, controls, documents and commissioning needs.
- Delivery address and schedule.
Email the package to yangle990706@gmail.com. BOYAN will confirm product fit, tooling and acceptance.
Compare Related BOYAN Circular Machines
For a larger 118.8 kg dog-leash and hemp-rope decorative wrapping platform, review the large circular rope winding machine. This page is the smaller 60 kg, 710 × 670 × 390 mm PWD-M-30 record and should not inherit the larger machine’s application data.
Browse the BOYAN winding machines category for related equipment.
Use our winding machine selection guide to compare control, material, package, speed, tension and application data before requesting a configuration.
Frequently Asked Questions
What products can it wind?
The source supports braiding-related and coil-winding applications. Exact product, material and size require drawings and samples.
What is the maximum ring diameter?
No product-diameter range is published. The machine size does not define the working envelope.
Does it guarantee uniform winding?
No numerical accuracy or tension specification is published. Neat formation is verified through agreed dimensional and visual criteria.
Does it include PLC and tension control?
The verified core component is a motor. PLC, servo, touchscreen and active tension control must be confirmed in the proposal if required.
What is the production speed?
No numerical speed or output is published. Accepted rate is established with the actual product and cycle.
Why do net and gross weight both show 60 kg?
The source lists both values as 60 kg. BOYAN will verify the final packed gross weight before shipment.
Is EU documentation available?
The source displays an EU label. Applicable documents and model coverage must be reviewed for the supplied configuration.
Request a Circular-Winding Review
Send the product drawing, material, supply package, winding pattern, cycle, quality criteria, output and destination power. BOYAN will determine whether this 60 kg PWD-M-30 platform is suitable.
Contact yangle990706@gmail.com for an automatic circular winding machine proposal based on verified source data.
